TD30480960 (400vac/48vdc 20A, 960W)

$ 766.65

Trade price New Zealand dollars + GST

TD ac-dc

  • Intended applications: Industrial DIN module switchmode power supply.
  • Classification: Class 1.
  • Protection: Short circuit, over voltage and overload shut down.
  • Construction: TS35 DIN rail (35mm symmetrical) mounting module, IP20
  • Input: Three phase 340~550vac L1, L2, L3 & E via terminals
  • Output: +ve & -ve via terminals (voltage adjustment range: + 20%)
  • Operating conditions: 47~63Hz, rated ambient temp 30 deg C.
  • Manufactured standard: ASNZS 60950.1.
  • Dimensions: H. 100mm, L. 227mm, W. 126mm, 2.67kg
SKU: TD30480960 Category:

Additional information

Weight 2.67 kg
Dimensions 126 x 227 x 100 mm

SDoC TD30480960-2015.pdf
