TS0240200 (230vac/24vdc 8.3A, 200W)

TS ac-dc

  • Intended applications: Industrial open frame switchmode power supply.
  • Classification: Class 1.
  • Protection: Short circuit, over voltage and overload shut down.
  • Construction: Euro vented metal cage, open frame IP00
  • Input: Single phase 115vac or 230vac (selectable) L, N & E via terminals.
  • Output: +ve & -ve via terminals (voltage adjustment range: +/- 10%)
  • Operating conditions: 47~63Hz, rated ambient temp 30 deg C.
  • Manufactured standard: ASNZS 60950.1.
  • Dimensions: H. 30mm, L. 215mm, W. 115mm, 0.73kg

Description

Non stock indent item – Contact [email protected] for pricing and availability

Additional information

Weight 0.73 kg
Dimensions 115 × 215 × 30 mm

SDoC TS0240200-2015.pdf
